Text Box: Inspection Equipment Starrett HB 350 optical comparator Micrometers to 12” Digital Calipers to 40” Gauge pins from .008” to .625” Gauge blocks Assorted dial indicators, depth gauges, and height gauges Dial bore gauges Renshaw probe for 4020 Fadal Radius and angle guages Surface finish gauge Materials and Process Control Large variety of material in house for same day emergency jobs including stainless steels, aluminums. bearing bronze and many plastics. Quality control manual available upon request Text Box: CNC Machines Fadal VMC 4020 40” x 20” x 28” travels (x y z) 4th axis pallet changer 31 position ATC 10,000 rpm spindle (2) Fadal VMC 40 22” x 16” x 20” travels (x y z) 21 position ATC 15,000 rpm spindle Fadal VMC 2216 22” x 16” x 20” travels (x y z) 21 position ATC 15,0000 rpm spindle Mori Seiki Jr. VMC 22” x 16” x 18” travels (x y z) 21 position ATC 10,000 rpm spindle ProtoTrak lathe TRL 1440P 14” x 40” work envelope (x z) 2400 rpm





Text Box: Support Equipment (2) Sharp manual milling machines DRO and power feed Leader engine lathe 15” x 40” work envelope (25” swing through gap) Hardinge Chucker Harig surface grinder MSC 39” vertical band saw Enco 9” x 16” horizontal band saw 5hp abrasive chop saw (4) Drill presses (4) Reversible tapping heads Assorted sand blasters, routers, sanders, grinders, and tumbling machines
